:CALCulate2:<function>:LIMit<Y>:STATe
This command enables or disables a limit test.
Type Affected by Where saved Default value
Command and query
Recall settings
Instrument reset
Power cycle
Measure configuration list
Save settings
Measure configuration list
0 (OFF)
Usage
:CALCulate2:<function>:LIMit<Y>:STATe <b>
:CALCulate2:<function>:LIMit<Y>:STATe?
<function>
The function to which this setting applies:
• Current: CURRent[:DC]
• Resistance: RESistance
• Voltage:
VOLTage[:DC]
<Y>
The limit that the setting applies to, 1 or 2
<b>
Enable the limit test: 1 or ON
Disable the limit test: 0 or OFF
Details
This command enables or disables a limit test for the selected measurement function.
If you send this command without the <function> parameter, it will set the state of math operations
for all functions.
Example
CALC2:VOLT:LIM1:LOW 0.25
CALC2:VOLT:LIM1:UPP 2.5
CALC2:VOLT:LIMIT1:STAT ON
CALC2:VOLT:LIMIT1:FAIL?
Set lower limit 1 for voltage to 0.25 volts.
Set upper limit 1 for voltage to 2.5 volts.
Enable limit 1 testing for voltage.
Check the test results.
Also see
None
