6: SCPI command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
6-138 2450-901-01 Rev. B/September 2013
:TRIGger:BLOCk:CONFig:RECall
This command recalls the system settings that are stored in a measure or source configuration list.
Type Affected by Where saved Default value
Command only
Recall settings
Instrument reset
Power cycle
Save settings
Not applicable
Usage
:TRIGger:BLOCk:CONFig:RECall <blockNumber>, <configurationList>
:TRIGger:BLOCk:CONFig:RECall <blockNumber>, <configurationList>, <point>
<blockNumber>
The sequence of the block in the trigger model
<configurationList>
The measure or source configuration list to recall
<point>
The point in the configuration list to recall; defaults to 1 if not selected
Details
When the trigger model reaches a configuration recall building block, the settings in the specified configuration
list are recalled.
You can restore a specific set of configuration settings in the configuration list by defining the index.
Example
SOUR:CONF:LIST:CRE "biasLevel"
SOUR:FUNC VOLT
SENS:FUNC "CURR"
SOUR:VOLT:LEV 5
SOUR:CONF:LIST:STORE "biasLevel"
TRIG:BLOCK:CONF:RECALL 1, "biasLevel", 1
Create a configuration list named
biasLevel. Set the source function to 5
volts and the measure function to current.
Store the configuration list.
Recall the configuration list as block 1 of the
trigger model.
Also see
Configuration lists (on page 3-33)
:SOURce[1]:CONFiguration:LIST:STORe (on page 6-65)

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
