Keithley 2450 User Manual

In this section:
Front-panel overview ................................................................ 2-1
Rear panel overview ................................................................ 2-7
Using the touch-screen interface .............................................. 2-8
Display features ..................................................................... 2-37
Dimensions ............................................................................ 2-39
Handle and bumpers .............................................................. 2-43
Remote communication interfaces ......................................... 2-44
Determining the command set you will use ............................ 2-65
System information ................................................................ 2-66
Instrument sounds .................................................................. 2-67
Test connections .................................................................... 2-68
Source-measure overview...................................................... 2-85
Protection ............................................................................... 2-98
Ranges ................................................................................. 2-101
Automatic reference measurements .................................... 2-108
Source readback .................................................................. 2-110
Source delay ........................................................................ 2-111
Saving setups ....................................................................... 2-112
Reset the instrument ............................................................ 2-116
Using the event log .............................................................. 2-117
Front-panel overview
The front panel of the Model 2450 is shown below. Descriptions of the controls on the front panel
follow the figure.
Figure 1: Model 2450 front panel
Section 2
General operation

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
