Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2450-901-01 Rev. B/September 2013 8-235
Example
tsplink.node = 3
Sets the TSP-Link node for this instrument to
number 3.
Also see
tsplink.initialize() (on page 8-231)
tsplink.state (on page 8-235)
tsplink.readport()
This function reads the TSP-Link synchronization lines as a digital I/O port.
Type TSP-Link accessible
Affected by Where saved Default value
Function
Yes
Usage
data = tsplink.readport()
data
Numeric value that indicates which lines are set
Details
The binary equivalent of the returned value indicates the input pattern on the I/O port. The least significant bit of
the binary number corresponds to line 1 and the value of bit 3 corresponds to line 3. For example, a returned
value of 2 has a binary equivalent of 010. This indicates that line 2 is high (1), and that the other two lines are low
(0).
Example
data = tsplink.readport()
print(data)
Reads state of all three TSP-Link lines.
Assuming line 2 is set high, the output is:
2.000000e+00
(binary 010)
The format of the output may vary depending on the
ASCII precision setting.
Also see
Triggering using TSP-Link synchronization lines (on page 3-113)
tsplink.line[N].state (on page 8-233)
tsplink.writeport() (on page 8-236)
tsplink.state
This attribute describes the TSP-Link online state.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (R)
Yes
Not applicable
Not applicable
Not applicable
Usage
state = tsplink.state
state
TSP-Link state (online or offline)
