Keithley 2450 User Manual

Appendix
C: Status model Model 2450 Interactive SourceMeter® Instrument
Reference Manual
C-14 2450-901-01 Rev. B/September 2013
Reading the registers
You can read any register in the Status Model. The response is a decimal value that indicates which
bits in the register are set. See Understanding bit settings (on page C-15
) for information on how to
convert the decimal value to bits.
Using SCPI commands:
If you are using SCPI, you use the query commands in the STATus subsystem and common
commands to read registers.
Using TSP commands:
If you are using TSP, you print the TSP command to read the register. You can use either print(),
which returns the decimal value, or print(tostring()), which returns the string equivalent of the
decimal value.
You can also send the common commands to read the register.
For example, you can send any one of the following commands to read the Status Enable register of
the Standard Event Register:
print(status.standard.enable)
*ese?
print(tostring(status.standard.enable))

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
