Keithley 2450 User Manual

Section
8: TSP command reference Model 2450 Interactive SourceMeter® Instrument
Reference Manual
8-192 2450-901-01 Rev. B/September 2013
This example uses the Simple Loop trigger model template to do a capacitor test. This example outputs 200
readings that have output similar to the following example output:
Rdg # Time (s) Current (A)
1 0 8.5718931952528e-11
2 0.151875 1.6215984111057e-10
3 0.303727 1.5521139928865e-10
. . .
198 29.91579194 1.5521250951167e-10
199 30.067648716 1.4131290582142e-10
200 30.219497716 1.5521067764368e-10
Also see
None
trigger.model.setblock() — trigger.BLOCK_BRANCH_ALWAYS
This function defines a trigger model block that always goes to a specific block.
Type TSP-Link accessible Affected by Where saved Default value
Function
Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
Not applicable
Usage
trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_ALWAYS, branchToBlock)
blockNumber
The sequence of the block in the trigger model
branchToBlock
The block number of the trigger model block to execute when the trigger model
reaches this block
Details
When the trigger model reaches a branch-always building block, it goes to the building block set by
branchToBlock.
Example
trigger.model.setblock(6, trigger.BLOCK_BRANCH_ALWAYS, 20)
When the trigger model reaches block 6, always branch to block 20.
Also see
None
