Model 2450

Interactive SourceMeter® Instrument Reference Manual Section 8:

TSP command reference

2450-901-01 Rev. B/September 2013 8-193

trigger.model.setblock() — trigger.BLOCK_BRANCH_COUNTER

This function defines a trigger model block that branches to a specified block a specified number of times.

Type TSP-Link accessible Affected by Where saved Default value

Function

Yes

Restore configuration

Instrument reset

Power cycle

Configuration script

Not applicable

Usage

trigger.model.setblock(blockNumber, trigger.BLOCK_BRANCH_COUNTER, targetCount,

branchToBlock)

blockNumber

The sequence of the block in the trigger model

targetCount

The number of times to repeat

branchToBlock

The trigger model block to execute when the counter is less than the

targetCount value

Details

This command defines a trigger model building block that branches to another block using a counter to iterate a

specified number of times.

Counters increment every time the trigger model reaches them until they are more than or equal to the count

value.

Example

trigger.model.setblock(4, trigger.BLOCK_BRANCH_COUNTER, 10, 2)

print(trigger.model.getbranchcount(4))

When the trigger model reaches this block, the trigger model returns to block 2. This repeats 10 times.

An example of the return if the trigger model has reached this block 5 times is:

Also see

trigger.model.getbranchcount() (on page 8-187)
