Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2450-901-01 Rev. B/September 2013 8-19
bufferVar.fillmode
This attribute determines if a reading buffer is filled continuously or is filled once and stops.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes
Restore configuration
Instrument reset
Power cycle
Configuration script
User-defined buffer: 0
defbuffer1: 1
defbuffer2: 1
Usage
fillMode = bufferVar.fillmode
bufferVar.fillmode = fillMode
fillMode
Fill the buffer, then stop: 0 or buffer.FILL_ONCE
Fill the buffer continuously: 1 or buffer.FILL_CONTINUOUS
bufferVar
The name of the reading buffer, which may be a default buffer (defbuffer1 or
defbuffer2
) or a user-defined buffer
Details
When a reading buffer is set to buffer.FILL_ONCE, no data is overwritten in the buffer. When the buffer is
filled, no more data is stored in that buffer and new readings are discarded.
When a reading buffer is set to buffer.FILL_CONTINUOUS, the oldest data is overwritten by the newest data
after the buffer fills.
When a reading buffer is set to buffer.FILL_CONTINUOUS, the first new measurement is stored at n+1, where
n is the number of readings stored in the buffer.

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
