Keithley 2450 User Manual

Section
3: Functions and features Model 2450 Interactive SourceMeter® Instrument
Reference Manual
3-60 2450-901-01 Rev. B/September 2013
Voltage sweep based on a configuration list
The following TSP example shows a voltage sweep that is based on a configuration list. It performs
the following actions:
• Reset the instrument to its defaults
• Create a source configuration list called CurrListSweep.
• Set the source function to current.
• Set the source current range to 100 mA.
• Set the source current level to 10 µA.
• Save the source settings to CurrListSweep.
• Set the source current level to 1 mA.
• Save the source settings to CurrListSweep.
• Set the source current level to 500 µA.
• Save the source settings to CurrListSweep.
• Set the source current level to 7 mA.
• Save the source settings to CurrListSweep.
• Set the source current level to 1 mA.
• Save the source settings to CurrListSweep.
• Set the source current level to 90 mA.
• Save the source settings to CurrListSweep.
• Set up a list sweep that uses the entries from the CurrListSweep configuration list and starts at
index 1 of the list.
• Set a source delay of 1 ms.
• Start the sweep.
No buffer is defined, so the data is stored in defbuffer1. See Reading buffers (on page 3-10
) for
more information on reading buffers.

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
