Keithley 2450 User Manual

S
ection 7: Introduction to TSP operation Model 2450 Interactive SourceMeter® Instrument
Reference Manual
7-20 2450-901-01 Rev. B/September 2013
Example: If and else
x = 2
if not x then
print("This is from the if block")
else
print("This is from the else block")
end
Output:
This is from the else
block
Example: Else and elseif
x = 1
y = 2
if x and y then
print("'if' expression 2 was not false.")
end
if x or y then
print("'if' expression 3 was not false.")
end
if not x then
print("'if' expression 4 was not false.")
else
print("'if' expression 4 was false.")
end
if x == 10 then
print("x = 10")
elseif y > 2 then
print("y > 2")
else
print("x is not equal to 10, and y is not greater than 2.")
end
Output:
'if' expression 2 was not false.
'if' expression 3 was not false.
'if' expression 4 was false.
x is not equal to 10, and y is not greater than 2.
\

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
