Keithley 2450 User Manual

S
ection 7: Introduction to TSP operation Model 2450 Interactive SourceMeter® Instrument
Reference Manual
7-22 2450-901-01 Rev. B/September 2013
Example: Repeat until
list = {
"One", "Two", "Three", "Four", "Five", "Six"}
print("Count elements in list using repeat:")
element = 1
repeat
print(element, list[element])
element = element + 1
until not list[element]
Output:
Count elements in list
using repeat:
1 One
2 Two
3 Three
4 Four
5 Five
6 Six
For loops
There are two variations of for statements supported in Lua: numeric and generic.
In a for loop, the loop expressions are evaluated once, before the loop starts.
The output you get from these examples may vary depending on the data format settings of the
instrument.
Example: Numeric for
list = {"One", "Two", "Three", "Four", "Five", "Six"}
---------- For loop -----------
print("Counting from one to three:")
for element = 1, 3 do
print(element, list[element])
end
print("Counting from one to four, in steps of two:")
for element = 1, 4, 2 do
print(element, list[element])
end
The numeric for loop repeats a block of code while a control variable runs through an
arithmetic progression.
Output:
Counting from one to three:
1 One
2 Two
3 Three
Counting from one to four, in steps of two:
1 One
3 Three

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
