Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 8:
TSP command reference
2450-901-01 Rev. B/September 2013 8-13
Example 2
buffer.save(MyBuffer, "/usb1/myDataRel.csv", buffer.SAVE_RELATIVE_TIME)
Save all readings and relative time stamps from
MyBuffer
to a file named
myDataRel.csv
on the USB
flash drive.
Example 3
buffer.save(defbuffer1, "/usb1/defbuf1data", buffer.SAVE_RAW_TIME)
Save readings and raw time stamps from defbuffer1 to a file named defbuf1data on the USB flash drive.
Uses the constant.
Example 4
buffer.save(defbuffer1, "/usb1/defbuf1data", 4)
Save readings and raw time stamps from defbuffer1 to a file named defbuf1data
on the USB flash drive.
Uses the numerical value.
Also see
buffer.make() (on page 8-11)
buffer.saveappend() (on page 8-14)
Reading buffers (on page 3-10)
Remote buffer operation (on page 3-27)

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
