Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 2:
General operation
2450-901-01 Rev. B/September 2013 2-59
You can also change the IP configuration through the front panel or with TSP and SCPI commands.
See Set up LAN communications on the instrument (on page 2-53) for information.
To change the IP configuration using the instrument web page:
1. Access the internal web page as described in the previous topic.
2. From the navigation bar on the left, in the LXI Home menu, select IP Config.
3. Click Modify. The Modify IP Configuration page is displayed.
Figure 40: Modify IP Config web page
4. Change the values.
5. Click Submit. The instrument reconfigures its settings, which may take a few moments.
You may lose your connection with the web interface after clicking Submit. This is normal and does
not indicate an error or failure of the operation. If this occurs, find the correct IP address and reopen
the web page of the instrument to continue.
Change the web interface password
You can change the instrument password from the web interface.
To change the password:
1. From the web interface home page, select Admin.
2. In the Current password box, enter the presently used password.
3. In the New password and Confirm new password boxes, enter the next password.
4. Click Submit.
The default password is admin.

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
