Machine Configuration (continued)
2-3
1 RADF (Reversing Automatic Document Feeder) automatically feeds
multiple originals one at a time to the platen glass for copying.
2 Toner access door opens to allow replenishing of toner.
3Work table provides a convenient workspace for documents both before
and after copying.
4 Key counter (option) manages the number of copies made on the
machine.
5 Multi-sheet bypass tray used for small quantity copying onto plain
paper or special paper.
6 Right side door opens to allow removal of mishandled paper.
7 Tray 4 (universal tray) is user-adjustable and holds 500 sheets from A3
to A5.
8 Tray 3 (universal tray) is user-adjustable and holds 500 sheets from A3
to A5.
9 Tray 2 is service-adjustable and holds 1,000 sheets of A4 or B5.
10 Tray 1 is service-adjustable and holds 1,500 sheets of A4 or B5.
HINT
Tray 1, 2, 3, 4 and LCT are available for loading wide types of the regu-
lar sizes specified above.
11 Front doors open to the internal copier to allow clearing of mishandled
paper.
12 FS-110 Finisher (option) sorts, staple-sorts, and groups into finished
sets.
With PK-110/120/120 Type-A Punching kit (option) installed, file holes
can be punched in the output copies.
With PI-110 Cover Sheet Feeder (option) installed, cover sheet paper
can be inserted in the output copies.
13 Sub power switch turns copier power On/Off when pressed.
14 LCD Touch screen displays interactive operation screens.
15 Control panel controls copier operations.
16 SF-101 Shift tray (option) sorts and groups into finished sets, and offsets
each set upon exit.
17 Main power switch turns machine power On/Off to operate it as copier/
scanner/server/printer.
18 LCT (Large Capacity Tray LT-402) (option) holds 4,000 sheets.
19 FS-111 Finisher (option) sorts, staple-sorts, and groups into finished
sets.
