Konica Minolta 7255 - PZ-108;PZ-109 Punching; Z-Folding Unit

Machine Configuration (continued)
2-13
PZ-108/PZ-109 Punching / Z-Folding Unit
1 Punching / Z-Folding unit front door opens to allow removal of mishan-
dled paper or waste paper.
2 Right lever opens to allow removal of mishandled paper.
3 Knob can be turned to ease removal of mishandled paper.
4Handle can be withdrawn to allow removal of mishandled paper.
5 Left lever opens to allow removal of mishandled paper.
6 Waste basket holds waste paper punched out.
1 Punching / Z-Folding unit front door
3 Knob
2 Right leve
r
4 Handle
5 Left lever
6 Waste basket
