MIDI Implementation
627
Status Second Third Description ( Use ..... ) ENA
[Hex] [H] [D] [H] [D]
Bn 4A (74) vv (vv) Sound Controller 5 ( for Filter Cutoff control ) C
Bn 4B (75) vv (vv) Sound Controller 6 ( for Decay Time control ) C
Bn 4C (76) vv (vv) Sound Controller 7 ( for LFO1 Speed control ) C
Bn 4D (77) vv (vv) Sound Controller 8 ( for LFO1 Pitch Depth control ) C
Bn 4E (78) vv (vv) Sound Controller 9 ( for LFO1 Delay control ) C
Bn 4F (79) vv (vv) Sound Controller 10 ( for Filter EG Intencity control ) C
Bn 50 (80) vv (vv) Multi Purpose Ctrl5 ( as AMS & FX Dmod Src = SW 1 ) C
Bn 51 (81) vv (vv) Multi Purpose Ctrl6 ( as AMS & FX Dmod Src = SW 2 ) C
Bn 52 (82) vv (vv) Multi Purpose Ctrl7 ( as AMS & FX Dmod Src = Foot Switch ) C
Bn 53 (83) vv (vv) Multi Purpose Ctrl8 ( as AMS & FX Dmod Src = CC#83 ) C
Bn 55 (85) vv (vv) ( as AMS & FX Dmod Src = XY Mod +X ) C
Bn 56 (86) vv (vv) ( as AMS & FX Dmod Src = XY Mod -X ) C
Bn 57 (87) vv (vv) ( as AMS & FX Dmod Src = XY Mod +Y ) C
Bn 58 (88) vv (vv) ( as AMS & FX Dmod Src = XY Mod -Y ) C
Bn 5B (91) vv (vv) Effect 1 Depth ( for Send 2 Level control ) C
Bg 5C (92) 00/≠00 (00/≠000) Effect 2 Depth ( for All Insert FX Off/On ) C
Bn 5D (93) vv (vv) Effect 3 Depth ( for Send 1 Level control ) C
Bg 5E (94) 00/≠00 (00/≠000) Effect 4 Depth ( for Master FX1,2 Off/On ) C
Bg 5F (95) 00/≠00 (00/≠000) Effect 5 Depth ( for Total FX Off/On ) C
Bn 60 (96) 00 (00) Data Increment ( for RPC edit ) C
Bn 61 (97) 00 (00) Data Decrement ( for RPC edit ) C
Bn 64 (100) 0r (0r) RPN Param No. (LSB) ( for RPN select ) *3 C
Bn 65 (101) 00 (00) RPN Param No. (MSB) ( for RPN select ) *3 C
Bn 66 (102) ≤3F/≥40 (≤63/≥64) ( as KARMA SW1 ) *4 C
Bn 67 (103) ≤3F/≥40 (≤63/≥64) ( as KARMA SW2 ) *4 C
Bn 68 (104) ≤3F/≥40 (≤63/≥64) ( as KARMA SW3 ) *4 C
Bn 69 (105) ≤3F/≥40 (≤63/≥64) ( as KARMA SW4 ) *4 C
Bn 6A (106) ≤3F/≥40 (≤63/≥64) ( as KARMA SW5 ) *4 C
Bn 6B (107) ≤3F/≥40 (≤63/≥64) ( as KARMA SW6 ) *4 C
Bn 6C (108) ≤3F/≥40 (≤63/≥64) ( as KARMA SW7 ) *4 C
Bn 6D (109) ≤3F/≥40 (≤63/≥64) ( as KARMA SW8 ) *4 C
Bn 6E (110) vv (vv) ( as Pad1 (vv) = 1-127 Velocity) *4 C
Bn 6F (111) vv (vv) ( as Pad2 (vv) = 1-127 Velocity) *4 C
Bn 70 (112) vv (vv) ( as Pad3 (vv) = 1-127 Velocity) *4 C
Bn 71 (113) vv (vv) ( as Pad4 (vv) = 1-127 Velocity) *4 C
Bn 72 (114) vv (vv) ( as Pad5 (vv) = 1-127 Velocity) *4 C
Bn 73 (115) vv (vv) ( as Pad6 (vv) = 1-127 Velocity) *4 C
Bn 74 (116) vv (vv) ( as Pad7 (vv) = 1-127 Velocity) *4 C
Bn 75 (117) vv (vv) ( as Pad8 (vv) = 1-127 Velocity) *4 C
Bn 76 (118) vv (vv) ( as XY Control Mode X ) *4 C
Bn 77 (119) vv (vv) ( as XY Control Mode Y ) *4 C
Bn cc (cc) vv (vv) Control data ( for Seq. recording (cc) = 0-119 ) C,Q
Bn 78 (120) 00 (00) All Sound Off C
Bn 79 (121) 00 (00) Reset All Controllers C
Bn 7A (122) 00/7F (00/127) Local Control Off/On A
Bn 7B (123) 00 (00) All Notes Off A
Bn 7C (124) 00 (00) Omni Mode Off ( as All Notes Off ) A
Bn 7D (125) 00 (00) Omni Mode On ( as All Notes Off ) A
Bn 7E (126) ≤10 (≤16) Mono Mode On ( as All Notes Off ) A
Bn 7F (127) 00 (00) Poly mode On ( as All Notes Off ) A
Cn pp (pp) -- -- Program Change ( for Prog/Combi change ) *1 P
Dn vv (vv) -- -- Channel Pressure ( as After Touch ) T
En bb (bb) bb (bb) Bender Change C
AMS : Alternate Modulation Source
FX Dmod Src : Effect Dynamic Modulation Source
n : MIDI Channel No. (0 - 15) •••••• Usually Global Channel.
When in Combination/Sequencer mode, each timbre's/track's channel.(Status is INT or BTH)
For KARMA Module input in Combination/Sequencer mode, Input Channel of each KARMA Module
g : Always Global Channel No. (0 - 15)
x : Random
ENA : Same as Transmitted data
*1 : When Bank Map in Global mode is KORG;
MIDI In [Hex] Program Combination
mm,bb,pp = 00,00, 00 - 7F : Bank INT-A 000 - 127 : Bank INT-A 000 - 127
00,01, 00 - 7F : INT-B 000 - 127 : INT-B 000 - 127
00,02, 00 - 7F : INT-C 000 - 127 : INT-C 000 - 127
00,03, 00 - 7F : INT-D 000 - 127 : INT-D 000 - 127
00,04, 00 - 7F : INT-E 000 - 127 : INT-E 000 - 127
00,05, 00 - 7F : INT-F 000 - 127 : INT-F 000 - 127
00,06, 00 - 7F : : INT-G 000 - 127
00,08, 00 - 7F : USER-A 000 - 127 : USER-A 000 - 127
00,09, 00 - 7F : USER-B 000 - 127 : USER-B 000 - 127
00,0A, 00 - 7F : USER-C 000 - 127 : USER-C 000 - 127
00,0B, 00 - 7F : USER-D 000 - 127 : USER-D 000 - 127
00,0C, 00 - 7F : USER-E 000 - 127 : USER-E 000 - 127
00,0D, 00 - 7F : USER-F 000 - 127 : USER-F 000 - 127
00,0E, 00 - 7F : USER-G 000 - 127 : USER-G 000 - 127
79,00, 00 - 7F : G 001 - 128
79,01-09, 00 - 7F : g(1)-g(9) 001 - 128
78,00, 00 - 7F : g(d) 001 - 128
38,00, 00 - 7F : G 001 - 128
3E,00, 00 - 7F : g(d) 001 - 128
When Bank Map in Global mode is GM(2);
MIDI In [Hex] Program Combination
mm,bb,pp = 3F,00, 00 - 7F : Bank INT-A 000 - 127 : Bank INT-A 000 - 127
3F,01, 00 - 7F : INT-B 000 - 127 : INT-B 000 - 127
3F,02, 00 - 7F : INT-C 000 - 127 : INT-C 000 - 127
3F,03, 00 - 7F : INT-D 000 - 127 : INT-D 000 - 127
3F,04, 00 - 7F : INT-E 000 - 127 : INT-E 000 - 127
3F,05, 00 - 7F : INT-F 000 - 127 : INT-F 000 - 127
3F,06, 00 - 7F : : INT-G 000 - 127
3F,08, 00 - 7F : USER-A 000 - 127 : USER-A 000 - 127
3F,09, 00 - 7F : USER-B 000 - 127 : USER-B 000 - 127
3F,0A, 00 - 7F : USER-C 000 - 127 : USER-C 000 - 127
3F,0B, 00 - 7F : USER-D 000 - 127 : USER-D 000 - 127
3F,0C, 00 - 7F : USER-E 000 - 127 : USER-E 000 - 127
3F,0D, 00 - 7F : USER-F 000 - 127 : USER-F 000 - 127
3F,0E, 00 - 7F : USER-G 000 - 127 : USER-G 000 - 127
79,00, 00 - 7F : G 001 - 128
79,01-09, 00 - 7F : g(1)-g(9) 001 - 128
78,00, 00 - 7F : g(d) 001 - 128
00,00, 00 - 7F : G 001 - 128
38,00, 00 - 7F : G 001 - 128
3E,00, 00 - 7F : g(d) 001 - 128
3F,7F, 00 - 7F : Mute (KORG MUTE)
*2 : When in Program/Sampling mode, Global channel.
When in Combination/Sequencer mode, each IFX's channel.
*3 : r = 0 : Pitch Bend Sensitivity ( Bend Range )
= 1 : Fine Tune ( Detune )
= 2 : Coarse Tune ( Transpose )
For drum program, both of Fine Tune and Coase Tune affect to Detune.
Data Entry LSB value has no effect for Pitch Bend Sensitivity and Coarse Tune.
*4 : When CC# by "CC Default" is assigned to the KARMA Controllers, XY Mode X, Y and Pads
in Global Mode.
n : When in Program/Combination mode, Global channel.
When in Sequencer mode, current selected track's channel.
