Page #638 background imageLoading...
Page #638 background image
Appendices
628
2-2 SYSTEM COMMON MESSAGES [H] :Hex, [D] :Decimal
Status Second Third Description ( Use for ..... )
[Hex] [H] [D] [H] [D]
F2 ss (ss) tt (tt) Song Position Pointer ( Location ) *6
ss : Least significant [LSB]
tt : Most significant [MSB]
F3 ss (ss) Song Select (Song or Cue List select)
ss : Song(0-127) No.
Receive when in Sequencer mode.
2-3 SYSTEM REALTIME MESSAGES
Status[Hex] Description ( Use for..... )
F8 Timing Clock ( Tempo, AMS & FX Dmod Src ) *5
FA Start ( Seq Start & KARMA Control ) *6
FB Continue ( Seq Continue start & KARMA Control ) *6
FC Stop ( Seq Stop & KARMA Control ) *6
FE Active Sensing ( MIDI Connect check )
*5 Receive when MIDI Clock in Global mode is External MIDI.
*6 Receive when MIDI Clock in Global mode is External MIDI
and Receive Ext. Realtime Commands in Global mode is checked.
2-4 SYSTEM EXCLUSIVE
2-4-1 UNIVERSAL SYSTEM EXCLUSIVE MESSAGE ( NON REALTIME )
DEVICE INQUlRY ( When received this message, transmits INQUlRY MESSAGE REPLY )
[ F0,7E,nn,06,01,F7 ] 3rd byte nn : Channel = 0 - F : Global Channel
= 7F : Any Channel
GM System On ( Receive when in Sequencer mode )
[ F0,7E,nn,09,01,F7 ] 3rd byte nn : Channel = 0 - F : Global Channel
= 7F : Any Channel
2-4-2 UNIVERSAL SYSTEM EXCLUSIVE MESSAGES ( REALTIME )
Master Volume
[ F0,7F,0g,04,01,vv,mm,F7 ] 3rd byte g : Global Channel
6th byte vv : Value(LSB)
7th byte mm : Value(MSB)
mm,vv = 00,00 - 7F,7F : Min - Max
Master Balance
[ F0,7F,0g,04,02,vv,mm,F7 ] 3rd byte g : Global Channel
6th byte vv : Value(LSB)
7th byte mm : Value(MSB)
mm,vv = 00,00:Left, 40,00:Center, 7F,7F:Right
Master Fine Tune ( Control Master Tune(cent) in Global )
[ F0,7F,0g,04,03,vv,mm,F7 ] 3rd byte g : Global Channel
6th byte vv : Value(LSB)
7th byte mm : Value(MSB)
mm,vv = 20,00:-50, 40,00:+00, 60,00:+50
Master Coarse Tune ( Control Transpose (chromatic step) in Global )
[ F0,7F,0g,04,04,vv,mm,F7 ] 3rd byte g : Global Channel
6th byte vv : Value(LSB)
7th byte mm : Value(MSB)
mm,vv = 34,00:-12, 40,00:+00, 4C,00:+12
