Lenze i950

Address Name / seng range / [default seng] Info
0x500C:030 Traversing range
•
Seng can only be changed if the inverter is inhibi-
t
ed.
Specicaon of the traversing range for the virtual master axis.
•
0: Linearly limited traversing range (spindle drive).
•
1: Unlimited traversing range (turntable). The cycle length must also
be specied here.
0 Modulo
1 Limited
0x500C:031 Cycle length
0.0001 ... [360.0000] ... 214748.3647
•
Seng can only be changed if the inverter is inhibi-
ted.
The cycle length for an unlimited traversing range denes at which posi-
on the measuring system is repeated (posion return to 0).
0x500C:045 Max. velocity
0.0000 ... [0.0000] ... 214748.3647
0x500C:046 Max. acceleraon
0.00 ... [0.00] ... 21474836.47
0x500C:047 Max. jerk
0.00 ... [0.00] ... 21474836.47
0x500C:048 Applicaon quick stop - deceleraon
0.01 ... [3600.00] ... 21474836.47
0x500C:049 Applicaon quick stop - jerk
0.00 ... [0.00] ... 21474836.47
0x500C:050 Enable soware limit switches
false Inacve
true Acve
0x500C:051 Soware limit switch posive
-214748.3648 ... [0.0000] ... 214748.3647
0x500C:052 Soware limit switch negave
-214748.3648 ... [0.0000] ... 214748.3647
0x500C:053 Acon
aer "soware limit switch reached"
0 Stop aer soware limit switch
1 Stop at soware limit switch
0x500C:105 Acon aer "soware limit switch reached"
19 Fault > Applicaon quick stop > Quick stop
21
0x500C:106 Response to "prole limit reached"
0 No Response
2 Warning
19 Fault > Applicaon quick stop > Quick stop
21
0x500C:150 SLS1
0.0000 ... [0.0000] ... 214748.3647
0x500C:151 SLS1 - deceleraon
me
0.000 ... [0.000] ... 2147483.647 s
0x500C:152 SLS2
0.0000 ... [0.0000] ... 214748.3647
0x500C:153 SLS2 - deceleraon me
0.000 ... [0.000] ... 2147483.647 s
0x500C:154 SLS3
0.0000 ... [0.0000] ... 214748.3647
0x500C:155 SLS3 - deceleraon me
0.000 ... [0.000] ... 2147483.647 s
0x500C:156 SLS4
0.0000 ... [0.0000] ... 214748.3647
0x500C:157 SLS4 - deceleraon
me
0.000 ... [0.000] ... 2147483.647 s
Conguring the "Sync and Correcon" TA
Mas
ter value sources
Virtual master
109
