Lenze i950

Precondions for the performance
•
The wiring of the thr
ee motor phases and the feedback must be carried out in accordance
with the specicaons from the hardware manual.
•
The motor may be stalled.
•
The servo inverter is error-free and in Switched on device state.
•
Please observe the notes in the Synchronous motor: Pole posion idencaon (PPI)sec-
on.
Response of the motor during performance
The current test pulses cause audible engine noises that may be increased by the machine
mechanics depending on the mechanic
al coupling!
How to execute the pole posion idencaon PLI (without movement):
1.
If the ser
vo inverter is enabled, disable it.Enable operaon
2.
Se
t the object 0x2825 to "7" to change to the "pole posion idencaon PLI (without
mo
vement)" operang mode.
3.
Enable the servo inverter to start the process.
Note: Inhibing the controller serves to abort the started procedure any me if required
without changing the sengs.
Aer the pole posion idencaon has been completed successfully...
...the controller is inhibited automacally and the pole posion determined for the acvated
feedback system is set in the 0x2C03:002 object.
•
F
or permanent storage, the changed sengs from the servo inverter must be uploaded in
the Con
troller.
The »EASY Starter« serves to save the parameter sengs of the servo inverter as parame-
ter le (*.gdc). Saving the parameter sengs
•
The in
verter disable set automacally by the procedure can be deacvated again via the
CiA402 c
ontrol word 0x6040. Enable operaon
Oponal sengs (starng performance)
Oponally, a pole posion idencaon without moon can be acvated aer switching on
the servo inverter.
Parameter
Address Name / seng range / [default seng] Info
0x2C63:001 PPI without movement: Execuon
•
Seng can only be changed if the inverter is inhibi-
t
ed.
Starng performance (with or without pole posion idencaon before
the start).
0 Deacvated No pole posion is idened.
1 Only aer 1st enable/encoder error Aer the rst controller enable and aer each encoder wire breakage, a
PLI without movement takes place.
CAUTION!
Aer an encoder wire breakage, the drive may accelerate in an uncon-
tr
olled manner subsequent to the pole posion idencaon.
•
Cause: In c
ase of a wire breakage, the feedback system state is unde-
ned and the pole posion assumes any value.
•
R
emedy: Set the error response "Warning" (0x2C450x2C45 = 2) for an
encoder wire breakage in order that the pole posion will be iden-
ed aer a wire breakage.
2 Aer each enable Aer every inverter release, the pole posion is idened without any
movement.
Conguring the feedback system
S
ynchronous motor: Pole posion idencaon (PPI)
Pole posion idencaon (PPI) without movement
235
