Address Designaon Default seng Data type Factor A M
0x2128 S-bus: Conguraon - (Read only) U8 -
0x2129:001 S-bus: Control bits: SD-Out1 - (Read only) BOOLEAN 1 X ●
0x212C:001 Safety: Soware: Safety:
Soware version - (Read only) STRING[50] X
0x212D:001 Safety: Hardware: Safety: Hardware version - (Read only) STRING[50] X
0x212D:002 Safety: Hardware: Safety: Type - (Read only) STRING[50] X
0x212D:003 Safety: Hardware: Safety: Serial number - (Read only) STRING[50] X
0x212D:004 Safety: Hardware: Safety: Producon date - (Read only) STRING[50] X
0x2130:001 Fault history: Actual fault type - (Read only) U8 X
0x2130:002 Fault history: Fault history 1 - (Read only) U16 HX
0x2130:003 Fault history: Fault history 2 - (Read only) U16 HX
0x2130:004 Fault history: Fault history 3 - (Read only) U16 HX
0x2130:005 Fault history: Fault history 4 - (Read only) U16 HX
0x2130:006 Fault history: Fault history 5 - (Read only) U16 HX
0x2130:007 Fault history: Fault history 6 - (Read only) U16 HX
0x2130:008 Fault history: Fault history 7 - (Read only) U16 HX
0x2130:009 Fault history: Fault history 8 - (Read only) U16 HX
0x2130:010 Fault history: Fault history 9 - (Read only) U16 HX
0x2130:011 Fault history: Fault history 10 - (Read only) U16 HX
0x2130:012 Fault history: Fault history 11 - (Read only) U16 HX
0x2130:013 Fault history: Fault history 12 - (Read only) U16 HX
0x2130:014 Fault history: Fault history 13 - (Read only) U16 HX
0x2130:015 Fault history: Fault history 14 - (Read only) U16 HX
0x2130:016 Fault history: Fault history 15 - (Read only) U16 HX
0x2130:017 Fault history: Fault history 16 - (Read only) U16 HX
0x2131:001 Safety: Operang me: Safety: Operang me x s (Read only) U32 1 X
0x2132 Safety module status - (Read only) U16 1 X
0x231F:001 Module ID: Acve module ID - (Read only) U8 X
0x231F:002 Module ID: Module ID connected - (Read only) U8 X
0x2371:009 EtherCAT on board: Interface mode Slave [0] U8 C
0x2372:009 Systembus
EtherCAT-Informaonen: Acve inter-
face mode
- (Read only) U8 -
0x2378 Network status - (Read only) U16 X ●
0x2379 Network error - (Read only) U16 1 -
0x2380 PROFINET communicaon No acon/no error [0] U8 X
0x2381:001 PROFINET sengs: IP address 0.0.0.0 U32 E
0x2381:002 PROFINET sengs: Subnet 0.0.0.0 U32 E
0x2381:003 PROFINET sengs: Gateway 0.0.0.0 U32 E
0x2381:004 PROFINET sengs:
Staon name STRING[240] -
0x2381:005 PROFINET sengs: I&M1 System designaon STRING[32] -
0x2381:006 PROFINET sengs: I&M1 Installaon site STRING[22] -
0x2381:007 PROFINET sengs: I&M2 Installaon date STRING[16] -
0x2381:008 PROFINET sengs: I&M3 addional informaon STRING[54] -
0x2381:009 PROFINET sengs: I&M4 signature code "00000000000000000000000000000000
000000000000000000000000000000000
000000000000000000000000000000000
0000000000"
OCTET[54] -
0x2382:001 Acve PROFINET sengs: IP address - (Read only) U32 EX
0x2382:002 Acve PROFINET sengs: Subnet - (Read only) U32 EX
0x2382:003 Acve PROFINET sengs: Gateway - (Read only) U32 EX
0x2382:004 Acve PROFINET sengs:
Staon name - (Read only) STRING[240] X
0x2382:005 Acve PROFINET sengs: MAC Address - (Read only) OCTET[6] X
0x2388 PROFINET status - (Read only) U16 HX
0x2389:001 PROFINET error: Error 1 - (Read only) U16 X
0x2389:002 PROFINET error: Error 2 - (Read only) U16 HX
* Default seng depending on the size.
