15 - 24
15. SERVO AMPLIFIER CONNECTION
15.6 Device Range that Can Be Set
(Continued to next page)
*1 For the parameters prefixed by an asterisk (*), setting
becomes effective when the power is turned off once and
back on after setting the parameter data.
(e) Status display
(f) Alarm
PRM22, PRM1022 Function selection 4 *OP4
PRM23, PRM1023 Feed forward gain FFC
PRM24, PRM1024 Zero speed ZSP
PRM25, PRM1025
Analog speed command
maximum speed
/limit maximum speed
VCM
PRM26, PRM1026
Analog torque command
maximum output
TLC
PRM27, PRM1027 Encoder output pulses *ENR
PRM28, PRM1028 Internal torque limit 1 TL1
PRM29, PRM1029
Analog speed command offset
/limit offset
VCO
PRM30, PRM1030
Analog torque command offset
/limit offset
TLO
PRM31,PRM1031 Analog monitor 1 offset MO1
PRM32, PRM1032 Analog monitor 2 offset MO2
PRM33, PRM1033
Electromagnetic brake
sequence output
MBR
PRM34, PRM1034
Ratio of load inertia moment to
servo motor inertia moment
GD2
PRM35, PRM1035 Position loop gain 2 PG2
PRM36, PRM1036 Speed loop gain 1 VG1
PRM37, PRM1037 Speed loop gain 2 VG2
PRM38, PRM1038 Speed integral compensation VIC
PRM39, PRM1039
Speed differential compensation
VDC
PRM40, PRM1040 For manufacturer setting
PRM41, PRM1041
Input signal automatic ON
selection
*DIA
PRM42, PRM1042 Input signal selection 1 *DI1
PRM43, PRM1043
Input signal selection 2 (CN1B-5)
*DI2
PRM44, PRM1044
Input signal selection 3 (CN1B-14)
*DI3
PRM45, PRM1045
Input signal selection 4 (CN1A-8)
*DI4
PRM46, PRM1046
Input signal selection 5 (CN1B-7)
*DI5
PRM47, PRM1047
Input signal selection 6 (CN1B-8)
*DI6
PRM48, PRM1048
Input signal selection 7 (CN1B-9)
*DI7
PRM49, PRM1049 Output signal selection 1 *DO1
PRM50, PRM1050 For manufacturer setting
PRM51, PRM1051 Function selection 6 *OP6
PRM52, PRM1052 For manufacturer setting
PRM53, PRM1053 Function selection 8 *OP8
PRM54, PRM1054 Function selection 9 *OP9
PRM55, PRM1055 Function selection A *OPA
PRM56, PRM1056
Serial communication
time-out selection
SIC
PRM57, PRM1057 For manufacturer setting
PRM58, PRM1058
Machine resonance
suppression filter 1
NH1
PRM59, PRM1059
Machine resonance
suppression filter 2
NH2
PRM60, PRM1060
Low-pass filter, adaptive
vibration suppression control
LPF
PRM61, PRM1061
Ratio of load inertia moment
to servo motor inertia moment 2
GD2B
PRM62, PRM1062
Position control gain 2
changing ratio
PG2B
PRM63, PRM1063
Speed control gain 2 changing
ratio
VG2B
PRM64, PRM1064
Speed integral compensation
changing ratio
VICB
PRM65, PRM1065 Gain changing selection *CDP
PRM66, PRM1066 Gain changing condition CDS
PRM67, PRM1067 Gain changing time constant CDT
PRM68, PRM1068 For manufacturer setting
PRM69, PRM1069
Command pulse multiplying
factor numerator 2
CMX2
Device name Item
Symbol
*1
Device name Item
Symbol
*1
PRM70, PRM1070
Command pulse multiplying
factor numerator 3
CMX3
PRM71, PRM1071
Command pulse multiplying
factor numerator 4
CMX4
PRM72, PRM1072
Internal speed command4/limit4
SC4
PRM73, PRM1073
Internal speed command5/limit5
SC5
PRM74, PRM1074
Internal speed command6/limit6
SC6
PRM75, PRM1075
Internal speed command7/limit7
SC7
PRM76, PRM1076 Internal torque limit 2 TL2
PRM77 to PRM84,
PRM1077 to PRM1084
For manufacturer setting
Device
name
Item Symbol
ST0 Cumulative feedback pulses
ST1 servo motor speed
ST2 Droop pulses
ST3 Cumulative command pulses
ST4 Command pulse frequency
ST5 Analog speed command voltage/limit voltage
ST6 Analog torque command voltage/limit voltage
ST7 Regenerative load ratio
ST8 Effective load ratio
ST9 Peak load ratio
ST10 Instantaneous torque
ST11 Within one-revolution position
ST12 ABS counter
ST13 load inertia moment ratio
ST14 Bus voltage
Device
name
Item Symbol
AL0 Current alarm number
AL1 Detailed data of current alarms
AL11
Servo status when alarm occurs cumulative
feedback pulses
AL12
Servo status when alarm occurs
servo motor speed
AL13 Servo status when alarm occurs droop pulses
AL14
Servo status when alarm occurs cumulative
command pulses
AL15
Servo status when alarm occurs command
pulse frequency
AL16
Servo status when alarm occurs analog
speed command voltage/limit voltage
AL17
Servo status when alarm occurs analog
torque command voltage/limit voltage
AL18
Servo status when alarm occurs regenerative
load ratio
AL19
Servo status when alarm occurs effective load
ratio
AL20
Servo status when alarm occurs peak load ratio
AL21
Servo status when alarm occurs
instantaneous torque
AL22
Servo status when alarm occurs within one-
revolution position
AL23 Servo status when alarm occurs ABS counter
AL24
Servo status when alarm occurs
load inertia moment ratio
