When installing the cutter solenoid, note the following.
• Joint the cutter cap and the CR lock kicker, push down the cutter cap and the CR lock kicker
together to install them onto the cutter holder.
• Make sure to join the cutter cap and the CR lock kicker.Otherwise, when turning the power ON,
the carriage cannot move from the origin point to the left.
表 4-78
No. Part name
1 CR lock kicker
2
Cutter cap
