Controls/Features
ItemDescription
MAXAirConditioningMode
Inthismode,themajorityoftheairowisdirectedtothe
panelairoutletsandtheairisrecirculatedinsidethe
vehiclewhiletherestoftheairisdirectedtotheoor.
A/Cisturnedon,blowerissettohigh,temperatureis
settofullcold,andtheinletdoorissettorecirculation.
Theblowerspeed,temperature,andtheinletdoorcan
beadjustedusingthedials.Usethismodetoblockout
anyoutsideodors,smoke,ordustandtocooltheinterior
rapidlyuponinitialstartupinveryhotorhumidweather.
1.Dot
Inthismode,themajorityoftheairowisdirectedto
thepanelairoutlets,therestoftheairisdirectedtothe
oor.TheA/Cison,andsetstofullcold,recirculation,
andtheblowerspeedtomedium.Theblowerspeed,
temperature,andtheinletdoorcanbeadjustedusing
theblowerspeeddial.
VentMode
Inthismode,themajorityoftheairowisdirectedtothe
panelairoutlets,whiletherestoftheairowisdirected
totheooroutlets.
2.Dot
Thismodeisamixofthemajorityoftheairdirectedto
thepanelairoutletsandtheresttotheooroutlets.
Bi-LevelMode
Thismodeisasplitofequalairowbetweenthepanel
airoutletsandtheooroutlets.
ItemDescription
3.Dot
Thismodeisamixofsomeoftheairdirectedtothe
panelairoutletsandthemajoritytotheooroutlets.
FloorMode
Inthismode,themajorityoftheairowisbeingdirected
totheooroutlets.Smalleramountsofairwillbe
directedtothewindshieldandsidewindowstohelp
maintainclearwindows.
4.Dot
Thismodewillincreaseairowtothewindshield,with
someairowbeingdirectedtothesidewindowoutlets
andtheooroutlets.TheA/Cwillbeactiveandtheinlet
doorwillforcefreshairintothecabtoreducehumidity
levelsandmoisturebuilduponthewindshield.
MixMode
Inthismode,halfoftheairowisdirectedtothedefrost
andsidewindowairoutletsandhalfoftheairowis
directedtotheoorairoutlets,whileA/Cairwillbe
activeandtheinletdoorwillforcefreshairintothecab
toreducehumiditylevelsandmoisturebuilduponthe
windshield.
5.Dot
Inthismode,therewillbeanincreaseinairowtothe
windshield,maintainingairowtothesidewindowair
outlets.TheA/Cwillbeactiveandtheinletdoorwill
forcefreshairintothecabtoreducehumiditylevelsand
moisturebuilduponthewindshield.
