NEC Australia Pty Ltd Xen Master & Xen Axis
4 - 82 Installing KSUs
A6-324000-642-01 – Release 4.0 May 2001
3. Secure the supplied anchor on top of the
battery box as shown in the diagram using
the 4 x 6mm screws supplied.
4. Install KSU on top of the anchor. For the
installation procedure, see steps 2 and 3 of
section 3.2, “Installing Basic Unit to Floor”.
3.10.3 Installing External Battery in EBB Box
Figure 4-37 Secure Anchor
Figure 4-38 Installing External Battery
