NEC Xen Master - Attach a Multiline Terminal to the System; Figure 8-2 Connect an ETW-Type Multiline Terminal to the Xen System

May 2001
System Hardware Manual 8 - 247
A6-324000-642-01 – Release 4.0 May 2001
3.3 Attach a Multiline Terminal to the System
1. Plug a telephone cord into the modular jack on the bottom side
of the Multiline Terminal.
2. Lead the cord out through the cord groove as shown in Figure
8-2 Connect an ETW-type Multiline Terminal to the Xen
system.
Figure 8-2 Connect an ETW-type Multiline Terminal to the Xen system
