May 2001
System Hardware Manual 7 - 241
A6-324000-642-01 – Release 4.0
May 2001
3.14.1 Connecting the PC to the KSU
Using an RS232C straight cable, connect the PC to one of
the COM ports on the KSU. Refer to Figure 7-77
Connecting a PC to the KSU.
The functions and the communication port connections
are:
Serial-port characteristics include:
Table 7-5 Functions and Communication Port Connections
Function Port
PC Programming COM 1
Least Cost Routing (LCR) COM 1
Station Message Detail Recording (SMDR) COM 2
Automatic Call Distribution (ACD) COM 4
(Xen Master only)
Table 7-6 Serial Port Characteristics
Characteristic Value
Baud Rate 19.2 K (maximum)
Parity None
Stop Bit 1 stop bit
Data Bit 8 bits
Port Type DCE
