4.9 External Equipment Interface
Input signal levels, impedance, contact ratings, and connector types
are listed for externally connected equipment.
4.9.1 Music on Hold/Station Background Music
4.9.2 Music for Station BGM and MOH via COI( )-U13/U19 ETU
EXP-UA 13 ETU 414 g 48 mm 290 mm 214 mm
HFU-UA (WH) Unit 201 g 86 mm 107 mm 133 mm
MIFA-U13 ETU 343 g 48 mm 290 mm 214 mm
MIFM-U13 ETU 349 g 48 mm 290 mm 214 mm
OPX(2)-U13 ETU 410 g 48 mm 290 mm 214 mm
PBR( )-U13 ETU 303 g 48 mm 290 mm 214 mm
PRI(1)-U13 ETU 303 g 48 mm 290 mm 214 mm
SLI(4)-U13 ETU 360 g 48 mm 290 mm 214 mm
SLI(8)-U13 ETU 400 g 48 mm 290 mm 214 mm
SLT(1)-U13 ADP 255 g 45 mm 70 mm 120 mm
TLI(2)-U13 ETU 391 g 48 mm 290 mm 214 mm
VDD-UA Unit 352 g 63 mm 224mm 275 mm
VDH2(8)-U13 ETU 522 g 48 mm 290 mm 214 mm
VMS(2/4/8)-U13 ETU 2903 g 48 mm 290 mm 214 mm
VRS(4)-U13 ETU 340 g 48 mm 290 mm 214 mm
WMU-UA Unit 301 g 104 mm 151 mm 180 mm
Note : Shipping weight includes the shipping carton and documentation.
Table 2-13 Weights and Dimensions (Continued)
Unit Shipping Weight Height Width Depth
Table 2-14 Music on Hold/Station Background Music
Auxiliary Input 0.6V PPS Signal Level
Input Impedance 600 Ω
Table 5-15 Music for Station BGM and MOH via COI( )-
U13/U19 ETU
Auxiliary Input 0.6 V PPS Signal Level
Input Impedance 600 Ω
