NEC Xen Master - CTA-UA Unit (Computer Telephony Application); Figure 7-21 Attaching an Xen Multiline Terminal to a PC; Figure 7-22 CTA-UA Unit

May 2001
System Hardware Manual 7 - 207
A6-324000-642-01 – Release 4.0 May 2001
3.4 CTA-UA Unit (Computer Telephony Application)
Computer Telephony Application allows a DTU-type Multiline
Terminal to be connected to a PC. The PC can then be used to
perform all of the functions of the Multiline Terminal by using a
TAPI-compatible application software.
The CTA-UA Unit is attached to the bottom of a DTU-type Multiline
Terminal.
Figure 7-21 Attaching an Xen Multiline Terminal to a PC
Figure 7-22 CTA-UA Unit
ACA-UA Unit
(AC adaptor)
