NEC Australia Pty Ltd Xen Master & Xen Axis
5 - 122 Installing Electronic Telephone Units
A6-324000-642-01 – Release 4.0
May 2001
On the Xen Master, the ACD MIS cable connects to COM4
on the KSU. It is a standard female RS-232C DCE port. A
straight RS-232C cable is required.
3.7 KMM(XXX)UA Unit
3.7.1 Description
The KMM(XXX)UA Unit is a feature module that mounts on
the MIFM-U13 ETU. This unit is required when LCR or
Caller ID scrolling and dialling features are used.
3.7.2 Installation
Like all ICs, this unit has a notch on one side. Find the
notch on the IC6 silkscreen, and before mounting align the
KMM(XXX)UA unit so that the notches are on the
same side.
3.8 KML(XXX)UA Unit
3.8.1 Description
The KML(XXX)UA Unit is a feature module that mounts on
the MIFM-U13 ETU. It is required when LCR is to be used.
3.8.2 Installation
Like all ICs, this unit has a notch on one side. Find the
notch on the IC6 silkscreen, and before mounting align the
KML(XXX)UA unit so the notches are on the same side.
3.9 KMA(XXX)UA Unit (Xen Master Only)
3.9.1 Description
The KMA(XXX)UA Unit is a feature module that mounts on
the MIFA-U13 ETU. It is required when ACD with MIS is a
required feature.
3.9.2 Installation
Like all ICs, this unit has a notch on one side. Find the
notch on the IC6 silkscreen, and before mounting align the
KMA(XXX)UA Unit so the notches are on the same side.
