NEC Australia Pty Ltd Xen Master & Xen Axis
2 - 34 System Specifications
A6-324000-642-01 – Release 4.0
May 2001
Special Dial Tone 440 240 IPM
Tone Burst 1 Tone 800 Continuous
Tone Burst 2 Tone 400 Continuous
Tie/DID Ringback Tone
425
25 Hz Mod
0.4 sec On
0.2 sec Off
0.4 sec On
2.0 sec Off
Camp-On Tone
Call Alert Notification
Attendant Tone Override
440 Continuous
DIT Alert Tone 480/620 Continuous
Call Forward Alert Tone
Call Forward
Configuration Tone
350/440
Table 2-22 Tone Patterns (Continued)
System Tone
(Fixed)
Frequency (Hz)
(Fixed)
Cadence
(Default)
Cycle
.125
.125
1 sec
1 sec
0.4
.02
0.4
2.0
0.7 sec
0.5 sec
.25 sec ON x 2~3 bursts
Table 2-23 Multiline Terminal Flash Patterns
LED Condition Colour Flash Patterns
W
I-Use
Busy
Incoming Call
I-Hold
Call Hold
Hold Recall
Transfer Recall
Live Monitoring Mode
Green
Red
Red
Green
Red
Green
Green
Green
Microphone ON Red
W
ICM
I-Use
ICM Incoming Call
Voice Over Broker
Red
Red
Red
Large LED
Incoming Internal Call
Incoming Outside Call
Message from Attendant
Voice Mail Message
Red
Green
Green
Red
