May 2001
System Hardware Manual 7 - 205
A6-324000-642-01 – Release 4.0
May 2001
5. Close the base plate, lead the AC adaptor cord out
through the hole, and snap the cover in place.
6. Plug in the power cord on the AC adaptor and the
telephone cord in the jack.
3.3.2 Switch Settings
There are two switch settings on the APR-UA Unit.
Figure 7-18 Closing the Base Plate Cover
Figure 7-19 APR-UA Unit Switches
