5.9 CNF(8)-U13 ETU
5.9.1 Description
The Multiline Conference Bridge allows any intercom user
and any outside party calling to a port of the CNF(8)-U13
ETU to make a multiparty conference call. One 8-party
conference or two 4-party conferences are supported and
regulated by a switch setting. System Software release 2
or higher is required.
5.9.2 Installation
A maximum of 2 CNF(8)-U13 ETUs can be installed in the
Xen Master system in slots S1~S8 of the first, second or
third KSU.
A maximum of 2 CNF(8)-U13 ETUs can be installed in the
Xen Axis system, in slots S2~S7.
Figure 5-41 CNF(8)-U13 ETU
