System Hardware Manual 6 - 181
A6-324000-642-01 – Release 4.0
May 2001
Installing DTU-Type
Multiline Terminals
Chapter 6
S
ECTION
1
G
ENERAL
I
NFORMATION
The Xen system provides six different Multiline Terminals, an Attendant
Console and several adaptors that allow peripheral equipment to be
attached to the Multiline Terminals. With the exception of the VDD-UA Unit,
the adaptors can also be used with DTU-type Multiline Terminals. This
chapter describes each terminal, console, and adaptor and provides
applicable installation instructions.
S
ECTION
2
M
ULTILINE
T
ERMINALS
2.1 DTU-8-1A (WH) TEL
This digital non-display Multiline Terminal is equipped with eight
programmable line keys (each with a two-colour LED), a built-in
speakerphone, headset jack, a large LED to indicate incoming calls
and messages, and compatibility with ADA-UA, APR-UA, CTA-UA,
CTU( )-UA, HFU-UA, and VDD-UA Units.
A maximum of 119 DTU-8-1 (WH) TELs can be installed in the Xen
Master system and a maximum of 31 in the Xen Axis system.
Figure 6-1 DTU-8-1A (WH) TEL Multiline Terminal
