NEC Xen Master - Figure 5-34 VRS(4)-U13 ETU

NEC Australia Pty Ltd Xen Master & Xen Axis
5 - 162 Installing Electronic Telephone Units
A6-324000-642-01 – Release 4.0 May 2001
5.4.2 Installation
✆ A maximum of 2 VRS(4)-U13 ETUs can be installed
in the Xen Master system, 3 per KSU in slots S1~S8
of the first, second or third KSU.
✆ A maximum of 2 VRS(4)-U13 ETUs can be installed
in the Xen Axis system, in slots S2~S7.
Figure 5-34 VRS(4)-U13 ETU
