System Hardware Manual 3 - 37
A6-324000-642-01 – Release 4.0
May 2001
Hardware Requirements
Chapter 3
S
ECTION
1
G
ENERAL
I
NFORMATION
The technician should be familiar with the Xen System before attempting to
install it. Review this chapter carefully.
S
ECTION
2
P
ROGRAMMING
S
TATIONS
Two programming positions are available in the Xen System. Station
equipment that is connected to the first ESI(8)-U13 ETU is automatically set
as programming positions and must be a display Multiline Terminal.
S
ECTION
3
A
TTENDANT
S
TATIONS
An unlimited number of Attendant positions can be assigned in the Xen
System. An Attendant Position can have one to four DCU-60-1A (WH)
Consoles attached. Each Attendant Console must be supported by an
ESI(8)-U13 ETU. A maximum of four Attendant Consoles can be installed
in each Xen System.
S
ECTION
4
P
ROGRAMMING
FROM
A
PC
Xen Systems can be programmed from a personal computer. The Menu
Programming option available with PC Programming allows the technician/
end-user easy access to all information that can be programmed on the Xen
System. The PC must be a Pentium or higher and have Windows 95 or
higher to be compatible with the Maintenance Access Terminal (MAT)
Software.
