May 2001
System Hardware Manual 5 - 165
A6-324000-642-01 – Release 4.0
May 2001
This ETU provides two, four or eight digital voice mail
ports. The 2- and 4-port require the included digital signal
processor (DSP); the 8-port configuration requires a DSP-
F-21 Unit. Refer to Table 5-15 Configuration Support
Table.
Table 5-15 Configuration Support Table
Function Configuration Support
Applications Automated Attendant/Voice Mail with call
forwarding (release transfer)
Automated Attendant/Voice Mail without call
forwarding (await answer transfer)
Voice Mail only (No transfer)
Message Notification Through message waiting lamps
Call Forwarding Supported
Applications Automated Attendant/Voice Mail with call
forwarding (release transfer)
Automated Attendant/Voice Mail without call
forwarding (await answer transfer)
Voice Mail only (No transfer)
Message Notification Through message waiting lamps
Call Forwarding Supported
Operator Console 100 (default)
Positive disconnect: Digital Signal
Hardware One VMS(2/4/8)-U13 ETU
Connections Connects to backplane connector of the KSU
Telephone One of the following telephones is required to
program Xen system data:
DTU-8D-1A(WH) TEL
DTU-16D-1A(WH) TEL
DTU-32D-1A(WH) TEL
ETW-16C-1A(SW) TEL (Not available in NZ)
ETW-16D-1A(SW) TEL (Not available in NZ)
ETW-24S-1A(SW) TEL (Not available in NZ)
DSP-F-21 Unit Adds four additional voice mail ports
Required by VMS(8)-U13 ETU
