NEC Xen Master - Figure 5-2 Wrist Strap Grounding; Figure 5-3 Handling an ETU

May 2001
System Hardware Manual 5 - 101
A6-324000-642-01 – Release 4.0 May 2001
✆ When inserting or removing an ETU, be sure the wrist strap is
connected to the Frame Ground Terminal on the KSU.
✆ When holding an ETU be sure you do not touch the
components or the soldered surfaces with your bare hands.
Place one hand under the bottom corner of the ETU and with
the other hand hold the ejector tab (located in the top corner of
the ETU).
Figure 5-2 Wrist Strap Grounding
Figure 5-3 Handling an ETU
Eject
