NEC Australia Pty Ltd Xen Master & Xen Axis
3 - 38 Hardware Requirements
A6-324000-642-01 – Release 4.0
May 2001
S
ECTION
5
P
ROGRAMMING
FROM
A
M
ULTILINE
T
ERMINAL
Programming for the Xen System is accomplished through PC
Programming. As an added convenience, programming for the system can
be accomplished using Multiline Terminals with LCD. Multiline Terminal
programming should be used after the system is installed and any initial
assignments are made. Using the Multiline Terminal provides a quick way to
access system data and make changes to data items. To program from a
Multiline Terminal one of the following terminals is required.
✆ DTU-8D-1A(WH) TEL
✆ DTU-16D-1A(WH) TEL
✆ DTU-32D-1A(WH) TEL
✆ ETW-16C-1A(SW) TEL
✆ ETW-16D-1A(SW) TEL
✆ ETW-24S-1A(SW) TEL
# ETW-type TEL are not available in New Zealand.
S
ECTION
6
X
EN
M
ASTER
R
EMOTE
PC P
ROGRAMMING
The Xen System can be programmed from a remote location using a
personal computer.
6.1 Remote Programming
To provide remote programming the following hardware is required:
✆ Analogue CO Trunk or system SLT Port (not needed if the
optional internal modem is used)
✆ A straight RS-232C cable and adaptor (provided with the
MIFM-U13 ETU) cable to connect a locally provided modem
(not needed if the optional internal modem is used)
✆ MIFM-U13 ETU installed in the Xen System
To Next Page
