NEC Australia Pty Ltd Xen Master & Xen Axis
5 - 156 Installing Electronic Telephone Units
A6-324000-642-01 – Release 4.0
May 2001
Figure 5-29 VDH2(8)-U13 ETU Connections
Figure 5-30 10 Base 2 Cable Connections
BNC
Connector
Jacks (1~8)
Terminating
Plug
External LAN or
Next VDH2(8)-U13
ETU
