S
ECTION
7
D
ETERMINING
R
EQUIRED
E
QUIPMENT
To determine equipment type and quantity to be installed, the technician
must be familiar with station equipment available and interface ETUs.
7.1 Station Equipment
The station equipment that can be installed with the Xen System is
listed below:
# ETW-type TEL are not available in New Zealand.
7.2 Interface ETUs
The slots in the Xen Master KSUs are completely flexible except for
the first slot in each KSU that is reserved for the CPUB( )-U13 ETU
or EXP-U13 ETU. Table 3-2 Interface Slot and System Port
Numbers for a Xen System shows the slot and port numbers.
The MIFA-U13 ETU must be installed in the ISA slot for MIS (part of
the ACD feature) to work.
MIFM-U13 ETU must be installed in slots S1 or S2 for the internal
socket modem to work. It can be installed in the ISA slot or S1/S2 if
a locally provided external modem is used.
The slots in the Xen Axis KSU are also flexible in their cord
assignments, except for some specific cases which will be detailed
later in this manual. Slot 1 is dedicated to the first eight ESI ports
and is actually built in to the mainboard along with the system’s
CPU.
The MIFM-U13 ETU must be installed in slot S2 for the internal
socket modem to work.
Table 3-1 Station Equipment Table
Equipment Description
DTU-8-1A(WH) TEL 8-line digital Multiline Terminal without LCD
DTU-8D-1A(WH) TEL 8-line digital Multiline Terminal with LCD and
softkeys
DTU-16D-1A(WH) TEL 16-line digital Multiline Terminal with LCD and
softkeys
DTU-32D-1A(WH) TEL 32-line digital Multiline Terminal with LCD and
softkeys
DCU-60-1A(WH) CONSOLE Attendant Console with 60 programmable line
keys
ETW-8E-1A(SW) TEL 8-line Multiline Terminal without LCD
ETW-16C-1A(SW) TEL 16-line Multiline Terminal with LCD
ETW-24S-1A(SW) TEL 24-line Multiline Terminal with LCD
EDW-48-2A(SW) Console 48-button DSS/BLF Console with 12 additional
function buttons
