5 - 112 Installing Electronic Telephone Units
A6-324000-642-01 – Release 4.0 May 2001
3.3.2 Switch Settings
The following Table 5-2 MIFM-U13 Switch Settings
indicates the default switch settings.
Figure 5-10 KSU MBD-U13 Unit
SW1-1 SW1-2 Description
Off Off
Normal Operation
On
Off
Flash ROM load from COM1 port
Off On
Factory Test
On
On
Flash ROM load from EPROM
SW1-3 Description
Off
Not Used
SW2
Description
Momentary Switch
System Reset
SW3-1 Description
