NEC Australia Pty Ltd Xen Master & Xen Axis
2 - 30 System Specifications
A6-324000-642-01 – Release 4.0
May 2001
4.8 Weights and Dimensions
Table 2-13 Weights and Dimensions indicates the shipping weight,
height, width, and depth of each of the Xen KSUs, ETUs, Multiline
Terminals and Adapters.
Table 2-13 Weights and Dimensions
Unit Shipping Weight Height Width Depth
ACA-UA Unit 638 g 86 mm 107 mm 133 mm
ADA-UA Unit 65 g 29 mm 59 mm 99 mm
APR-UA Unit 122 g 66 mm 59 mm 121 mm
B48-U13 KSU 13063 g 340 mm 350 mm 228 mm
B64-U13 KSU 13063 g 333 mm 348 mm 213 mm
BIU(2)-13 ETU 414 g 48 mm 290 mm 214 mm
BRT(4)-U13 ETU 414 g 48 mm 290 mm 214 mm
BSC-U13 ETU 414 g 48 mm 290 mm 214 mm
BSU(2)-U13 ETU 370 g 48 mm 290 mm 214 mm
CAD-F(8)-13 ADP 414 g 110 mm 320 mm 155 mm
CNF(8)-U13 ETU 325 g 48 mm 290 mm 214 mm
COI(8)-U13/U19 ETU 471 g 48 mm 290 mm 214 mm
COID(8)-U13/U19 ETU 490 g 48 mm 290 mm 214 mm
CPUB( )-U13 ETU 380 g 48 mm 290 mm 214 mm
CTA-UA Unit 122 g 66 mm 59 mm 121 mm
DCU-60-1(WH) Console 1503 g 92 mm 223 mm 270 mm
DID(4)-U13 ETU 439 g 48 mm 290 mm 214 mm
DPH(4)-U13 ETU 343 g 48 mm 290 mm 214 mm
DTU-16D-1A (WH) TEL 1233 g 123 mm 197 mm 235 mm
DTU-32D-1A (WH) TEL 1361 g 123 mm 220 mm 235 mm
DTU-8-1A (WH) TEL 1163 g 123 mm 197 mm 235 mm
DTU-8D-1A(WH) TEL 1163 g 123 mm 197 mm 235 mm
E64-U13 KSU 13063 g 333 mm 348 mm 213 mm
ECR-U13 ETU 344 g 40 mm 140 mm 180 mm
EDW-48-2A (SW) TEL 1389 g 69 mm 175 mm 223 mm
ESI(8)-U13 ETU 411 g 48 mm 290 mm 214 mm
ETW-16C-1A (SW) TEL 992 g 101mm 175 mm 223 mm
ETW-16D-1A (SW) TEL 1106 g 101mm 205 mm 223 mm
ETW-24S-1A (SW) TEL 1106 g 101mm 205 mm 223 mm
ETW-8E-1A (SW) TEL 907 g 101mm 175 mm 223 mm
