NEC Australia Pty Ltd Xen Master & Xen Axis
7 - 228 Installing Optional Equipment
A6-324000-642-01 – Release 4.0
May 2001
.
3.8.2 Wall Mounting the SLT(1)-U13 ADP
1. Remove the two screws from the top to open the SLT
adaptor as shown in Figure 7-56 Removing the
Screws from the SLT(1)-U13 ADP.
Figure 7-55 Connecting the SLT(1)-U13 ADP
1
4
ESI ETU
Modular Terminal Connections
Single Line Telephone Connections
To ESI
SLT(1)-U13 ADP
GN
RD
Y
BL
T
R
ESI Port
Base Cord
Modular Terminal
3
Figure 7-56 Removing the Screws from the SLT(1)-U13 ADP
