NEC Xen Master System Hardware Manual

NEC Australia Pty Ltd Xen Master & Xen Axis
2 - 32 System Specifications
A6-324000-642-01 – Release 4.0 May 2001
4.9.3 External Paging (Audio)
4.9.4 External Tone Ringer/Night Chime Output
4.9.5 SMDR Output
4.9.6 PC Connection
4.9.7 ACD/MIS Connector
4.9.8 Relay Contact
Table 5-16 External Paging (Audio)
Output Power -10 dBm Signal Level
Output Impedance 600 Ω
Relay Contact Rating 500 mA, 24 Vdc
Table 5-17 External Tone Ringer/Night Chime Output
Output Power -10 dBm
Output Impedance 600 Ω
Relay Contact Rating 500 mA, 24 Vdc
Table 5-18 SMDR Output
Female Connector (System
Output)
Standard RS-232C
(straight)
Table 5-19 PC Connection
Female Connector (System
Output)
Standard RS-232C
(straight)
Table 5-20 ACD/MIS Connector
Female Connector (System
Output)
Standard RS-232C
(straight)
Table 5-21 Relay Contact
All Relay Contact Ratings 500 mA, 24 Vdc

NEC Xen Master Specifications

General

Brand	NEC
Model	Xen Master
Category	Telephone
Language	English
