4.9.4 LED Indications
Live LED indications are listed below.
✆ Blinking Red Normal Operation
✆ Steady Red Operation Stopped (power still on)
✆ Off No Power
LED1 indications are listed below.
✆ Steady Red Some port(s) busy
✆ Off All ports idle
4.9.5 Connectors
The following connector is located on the ESI(8)-U13 ETU.
✆ CN1 Connects to the backboard
