NEC Australia Pty Ltd Xen Master & Xen Axis
7 - 226 Installing Optional Equipment
A6-324000-642-01 – Release 4.0
May 2001
• Records audio from the calling or called party of a telephone
conversation
• Records audio from both parties of a telephone conversation
• Records audio (or music) from a microphone, line-level device, or
CD player
• Plays live or recorded audio (or music) through an adjunct
telephone, handset or stereo speakers
The PC Board uses Computer Telephony Integration (CTI)
technology through Microsoft Windows 95 or higher to support
speech and data transmission, allow a variety of attachment
devices, and support complex calling features such as conference
calls, call waiting, and voice mail.
The PC Board supports the following terminals:
✆ DTU-type Multiline Terminals.
✆ ETW-type Multiline Terminals
The NEC PC Telephony board can be installed on the ISA bus on
any IBM-compatible PC.
Refer to the PCT Installation Guide provided with the PCT-UA for
installation instructions.
3.7.1 Connecting a MIC/Line-In
✆ If using the microphone input (MIC), connect an
electric condenser microphone. Phantom power
(-2.2 Vdc) is supplied.
✆ If using the line-level input (Line-In), connect to a line-
level device such as a CD or cassette player.
