NEC Xen Master System Hardware Manual

vi Table of Contents
NEC Australia Pty Ltd Xen Master & Xen Axis
A6-324000-642-01 - Release 4.0 May 2001
Chapter 7 Installing Optional Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .193
Section 1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Section 2 Preparing Multiline Terminal for Adapter Installation . . . . . . . . . . 193
Section 3 Installation Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
3.1 ACA-UA Unit (AC adaptor) . . . . . . . . . . . . . . . . . . . . . . . . . 196
3.2 ADA-UA Unit (Ancillary Device Adapter) . . . . . . . . . . . . . . 197
3.3 APR-UA Unit (Analogue Port Ringer) . . . . . . . . . . . . . . . . . 203
3.4 CTA-UA Unit (Computer Telephony Application) . . . . . . . . 207
3.5 Computer Telephony Adapter with USB Interface . . . . . . . . 209
3.6 HFU-UA (WH) Unit (Handsfree Unit) . . . . . . . . . . . . . . . . . . 223
3.7 PCT( )-U13 Unit (PC Telephony Board). . . . . . . . . . . . . . . 225
3.8 SLT(1)-U13 ADP (Single Line Telephone) . . . . . . . . . . . . . . 227
3.9 VDD-UA Unit (Voice/Data Unit for Digital Terminals). . . . . . 229
3.10 Wall Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
3.11 Music on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 239
3.12 Station Background Music . . . . . . . . . . . . . . . . . . . . . . . . . . 240
3.13 Paging Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 240
3.14 Connecting a KSU to a Personal Computer . . . . . . . . . . . . 240
Chapter 8 Installing ETW-Type Multiline Telephones. . . . . . . . . . . . . . . . . . . . . .245
Section 1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Section 2 ETW-type Multiline Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
Section 3 Connecting an Etw-type Multiline Terminal to the Xen System . . 246
3.1 Terminal Update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 246
3.2 Modular Terminal Connections . . . . . . . . . . . . . . . . . . . . . . 246
3.3 Attach a Multiline Terminal to the System . . . . . . . . . . . . . . 247
Appendix A Glossary ofAbbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .249
