Insert a new tape roll
1.
Place the new roll and close the side plate. Make certain that the roll is placed with the
holes to the back and the protection sheet to the front; see the illustration below.
[195] Positioning the new roll
2.
Loosen the end of the roll and lead the tape over the large guide roller.
[196] Guiding the tape around the guide roller
Chapter 11 - System maintenance280
Insert a new tape roll
