R&S FSW Series User Manual

Remote Commands
R&S
®
FSW
1083User Manual 1173.9411.02 ─ 43
[SENSe:]CORRection:CVL:HARMonic........................................................................... 1085
[SENSe:]CORRection:CVL:MIXer..................................................................................1085
[SENSe:]CORRection:CVL:PORTs................................................................................ 1086
[SENSe:]CORRection:CVL:SELect................................................................................ 1086
[SENSe:]CORRection:CVL:SNUMber............................................................................ 1086
[SENSe:]CORRection:CVL:BAND <Type>
This command defines the waveguide band for which the conversion loss table is to be
used. This setting is checked against the current mixer setting before the table can be
assigned to the range.
Before this command can be performed, the conversion loss table must be selected
(see [SENSe:]CORRection:CVL:SELect on page 1086).
This command is only available with option B21 (External Mixer) installed.
Parameters:
<Band> K | KA | Q | U | V | E | W | F | D | G | Y | J | USER
Standard waveguide band or user-defined band.
For a definition of the frequency range for the pre-defined bands,
see Table 14-6).
*RST: F (90 GHz - 140 GHz)
Example:
CORR:CVL:SEL 'LOSS_TAB_4'
Selects the conversion loss table.
CORR:CVL:BAND KA
Sets the band to KA (26.5 GHz - 40 GHz).
Manual operation: See "Band" on page 428
[SENSe:]CORRection:CVL:BIAS <BiasSetting>
This command defines the bias setting to be used with the conversion loss table.
Before this command can be performed, the conversion loss table must be selected
(see [SENSe:]CORRection:CVL:SELect on page 1086.
This command is only available with option B21 (External Mixer) installed.
Parameters:
<BiasSetting> numeric value
*RST: 0.0 A
Default unit: A
Example:
CORR:CVL:SEL 'LOSS_TAB_4'
Selects the conversion loss table.
CORR:CVL:BIAS 3A
Manual operation: See "Write to CVL table" on page 425
See "Bias" on page 428
Setting Basic Measurement Parameters
