–"active modular"
Example: //Query probe type
PROB3:SET:TYPE?
Usage: Query only
Manual operation: See "Type" on page 372
14.7.6.4 External Generator Control
External generator control commands are available if the R&S FSW External Genera-
tor Control option (R&S FSW-B10) is installed.
For each measurement channel one external generator can be configured. To switch
between different configurations define multiple measurement channels.
For more information on external generator control see Chapter 8.2.4.2, "Basics on
External Generator Control", on page 382.
● Measurement Configuration................................................................................1095
● Interface Configuration........................................................................................1099
● Source Calibration...............................................................................................1101
● Programming Example for External Generator Control.......................................1104
Measurement Configuration
The following commands are required to activate external generator control and to con-
figure a calibration measurement with an external tracking generator.
SOURce<si>:EXTernal<gen>:FREQuency......................................................................1095
SOURce<si>:EXTernal<gen>:FREQuency:COUPling[:STATe].......................................... 1096
SOURce<si>:EXTernal<gen>:FREQuency[:FACTor]:DENominator....................................1096
SOURce<si>:EXTernal<gen>:FREQuency[:FACTor]:NUMerator....................................... 1097
SOURce<si>:EXTernal<gen>:FREQuency:OFFSet......................................................... 1097
SOURce<si>:EXTernal<gen>:POWer[:LEVel]................................................................. 1098
SOURce<si>:EXTernal<gen>[:STATe]............................................................................ 1098
SOURce<si>:POWer[:LEVel][:IMMediate]:OFFSet...........................................................1099
SOURce<si>:EXTernal<gen>:FREQuency <Frequency>
This command defines a fixed source frequency for the external generator.
Suffix:
<si>
.
irrelevant
<gen>
Parameters:
<Frequency> Source frequency of the external generator.
*RST: 1100050000
Default unit: HZ
Example: //Define frequency of the generator
SOUR:EXT:FREQ 10MHz
